High Flow - Piston-Sensed Regulator
Series 3832

Description

The 3832 series regulators are designed for high pressure applications up to 2500 psig involving applications with inlet pressures up to 3000 psig. The series features a main valve with a Cv of 0.08.

Features

  • Capable of high flows with only a small pressure drop.
  • Available in brass or stainless steel construction.
  • Unbalanced stem provides positive shut-off.

Applications

The 3833 series regulators are ideal to meet the requirements of systems where a high flow of gases needs to be delivered with good outlet pressure control.

Specifications

 38323832L
Max. Inlet Pressure: 3000 psig 3000 psig
Operating Temp. Range: -40°F to 165° -40°F to 165°
Flow Coefficient (Cv): 0.08 0.08
Inlet and Outlet: 1/4" NPT female 1/4" NPT female

Materials Of Construction

 3832B3832S
Body: brass 316 SS
Bonnet: nickel plated brass nickel plated brass
Main Valve Assembly: brass 316 SS
Main Valve Seat: Kel-F Kel-F
Seal: Viton PTFE (Teflon)
Gauges: Brass Stainless Steel
High Flow - Piston Sensed Regulator Series 3832
3832

How To Order

Model NumberDel. Press. Range psigDel. Press. Gauge psigInlet Press. Gauge psig
3832B-250-CGA* 0-250 0-400 0-4000
3832B-500-CGA* 0-500 0-600 0-4000
3832B-1000-CGA* 0-1000 0-2000 0-4000
3832B-1500-CGA* 0-1500 0-2000 0-4000
3832B-2000-CGA* 0-2000 0-4000 0-4000
3832B-2500-CGA* 0-2500 0-4000 0-4000
Options:
  • SS Diaphragm outlet valve installed: add suffix “DV” after model number.
  • SS Packed outlet valve installed: add suffix “PV” after model number.

*Specify CGA connection when ordering.
